Hawker 800XP Aileron - X-Rayed using Computerized Radiography in place of X-Ray Film

X-Ray Film image of a Falcon 20 Flight Spoiler. Note the dark (corroded) areas.

Crack on a CL-601 Thrust Reverser MainTrack

Corrosion on the inside diameter of a G-IV Winglet to Wing Attachment Fitting

Crack in a Sikorsky S-76 Vertical Stabilizer Skin at the Tail Rotor Gear Box Attachment Fitting

This crack was noted on a Phenom 300 Wing Rib with Eddy Current Inspection

This is the results after performing a Fluorescent Penetrant Test
